REV. 8-7-17 Page 5
Skytech: Smart Batt III
COMMUNICATION - SAFETY - TRANSMITTER - (C/S - T/X)
This remote control has a COMMUNICATION –SAFETY function built into its software to ensure the transmitter and receiver are com-
municating normally.
In all operating modes, the transmitter sends an RF signal every fteen minutes to the receiver indicating that the transmitter is within
the normal operating range of 20 feet. Should the receiver NOT receive this signal, the receiver will begin a 2 hour countdown. If the
receiver does not receive a signal from the transmitter in 2 hours, the receiver will shut off the appliance. The receiver will then emit a
series of rapid “beeps” for a period of 10 seconds. Then after 10 seconds of rapid beeping, the receiver will continue to emit a single
“beep” every 2 seconds until a transmitter MODE Button is pressed to reset the receiver.
AUTO SHUT DOWN
This remote control has an auto shut down feature incorporated into its system. When the transmitter mode is in the ON position, the
appliance will only run for 9 hours. After that it will shut down. To reactivate the appliance, press the MODE button.
CP (CHILDPROOF) FEATURE
This remote control includes a childproof feature that allows the user to “lock-out” operations from the transmitter.
• To activate and de-activate the childproof feature, press and hold the SETTING button behind the battery cover for 5 seconds (The
letters “CP” will briey appear on the LCD screen when childproof mode is activated).
• “CP” will appear on the LCD screen if any button is pressed while childproof mode is engaged.
• When this mode is engaged, all auto settings go on without interruption (like thermostat). Only manual functions are prevented.
BATTERY LIFE
Life expectancy of the alkaline batteries in the transmitter should be at least 12 months. Check and replace all batteries:
• Annually.
• When operating range becomes reduced.
• When transmissions are not received by the remote receiver.
• If the hand held transmitter batteries measure less than 2.5 volts (Both batteries in combination).
SYSTEM CHECK
ELECTRONIC IGNITION SYSTEMS
Learn the transmitter to the receiver. See next section below.
• Slide the 3-position button on the remote receiver to the ON position. The spark electrode should begin sparking to
ignite the pilot (the pilot may ignite after only one spark). After the pilot ame is lit, the main gas valve should open
and the main gas ame should ignite.
• Slide the button to OFF. The main gas ame and pilot ame should BOTH extinguish.
• Slide the button to REMOTE (the center position), and then press the ON button on the transmitter to turn the system
to ON. The spark electrode should begin sparking to ignite the pilot. After the pilot is lit, the main gas valve should
open and the main gas ame should ignite.
• Press the OFF button on the transmitter to OFF. The main gas ame and pilot ame should BOTH extinguish.
• Press the MODE button on the transmitter to change the system to THERMO. Advance the SET temperature on the
transmitter to a temperature of at least 2°F (1°C) above the ROOM temperature displayed on the LCD screen. With
this manual setting the normal thermostatic cycle is overridden and the system ame will ignite. Set the SET
• temperature to at least 2°F (1°C) below the room temperature and the system ame will extinguish in a few seconds.
Thereafter, it should continue to cycle ON and OFF thermostatically approximately every two minutes as the ROOM
temperature changes, but only when the temperature differential between ROOM and SET temperatures differ at least
2°F (1°C). (The 2°F differential is the factory setting).
LEARNING TRANSMITTER TO RECEIVER
This transmitter has one of 1,048,576 unique security codes. It may be necessary to program the remote receiver to “learn” the security
code of the transmitter upon initial use, if batteries are replaced, or if using a replacement transmitter.
• Make sure the receiver’s slide switch is in the REMOTE position.
• Press and release the LEARN button on the receiver.
• When you hear the “Beep”, press and hold the MODE button for about 2 seconds on the transmitter.
• You will then hear a series of beeps that indicate that your new transmitter has been accepted by the receiver.
