Slant/Fin Intrepid TR Series User Manual

TR Series
3
BOILER LOCATION
Provide a level, solid foundation for the boiler. Location should be near
the chimney so that the Flue Pipe Connector or Breeching to the chim
ney is short and direct.
A. The foundation must be capable of supporting the weight of
the boiler when filled with water:
B. The TR Series Boiler has full wet base sections which surround
fire box for maximum heat absorption of burning fuel, and low floor
temperature.
C. If boiler is to be located over buried conduit containing electric wires
or telephone cables, consult local codes or the National Board of
Fire Underwriters for specific requirements.
MINIMUM CLEARANCE
Provide accessibility clearance of 610 mm ( 24") from surfaces requiring
servicing (top and front) and 457 mm (18") on any side requiring pas
sage. The boiler shall be installed with the following MINIMUM clear
ances from combustible materials:
A. CHIMNEY CONNECTOR 457 mm (18")
B. BACK AND LEFT SIDE 152 mm (6") except as limited by 457 mm
(18") clearance for chimney connector
C. RIGHT SIDE 152 mm (6") except for allowing for Burner door fully
open which requires for:
Beckett Burner 191 mm (7
1
/2")
Riello E Series Burner 267 mm (10
1
/2")
D. FLOOR the boiler is approved for installation on a combustible
floor, but subject to any local code requirements. NOT to be
installed on or over carpet.
NOTE: As an alternate:
The burner door is removable so that the above service clearances are
not mandatory.
INSTALLATION REQUIREMENTS
Boiler
Size
TR- 20
TR-30
TR-40
TR-50
TR-60
TR-70
kg
200
250
300
355
405
455
lbs
440
550
660
785
895
1000
Approximate Total Weight of Boiler
Assembly, filled with water
84.1
–
83.8
–
83.4
–
In.
TR-30
TR-40
TR-50
GROSS OUTPUT
Boiler
Model
Number
*
OIL INPUT
mL/s† USGPH† kW MBH MBH MBH MBH MBH Sq. Ft. mmWater Steam
mL/s mL/sUSGPM USGPM
Round I.D. ×
Height
in × ft
mm × m
kW
kW
kW m
2
kW
NET OUTPUT CHIMNEY SIZE TANKLESS HEATER §§
Water
Water**
Water Steam
Steam
Steam**
Steam
FLUE SIZEAFUE %
RATINGS WITH BECKETT BURNER
1.15
1.31
1.68
1.89
2.20
2.47
1.10
1.25
1.60
1.80
2.10
2.35
45
51
66
74
86
96
154
175
224
252
294
329
39
44
55
63
72
80
132
149
188
214
246
272
39
–
55
–
72
–
132
–
188
–
246
–
34
38
48
55
63
69
117
131
170
190
223
237
30
–
43
–
56
–
101
–
146
–
191
–
39
–
56
–
74
–
421
–
606
–
796
–
152
152
178
178
203
203
84.8
83.5
84.4
83.3
84.0
–
6
6
7
7
8
8
202
214
246
261
284
296
3.20
3.40
3.90
4.15
4.40
4.70
189
–
221
–
252
–
3.00
–
3.50
–
4.00
–
6"×15'
152×4.6m
8"×15'
203×4.6m
Standard Working Pressure 207 kPa (30 PSI) water, 103 kPa (15 PSI) steam.
All boilers hydrostatically tested—A.S.M.E.
* ADD SUFFIX
X —Denotes no circulator and no thermostat
P —Packaged water boiler has tankless heater
PT —Packaged water boiler with tankless heater
PZ —Packaged steam boiler less tankless heater
PZT —Packaged steam boiler with tankless heater
§§ Tankless heater rating based on intermittent draw.
† Ratings apply to the use of light oil of 11,000 W/L (140,000 Btu per gallon.)
** The Net ratings shown are based on a piping and pick-up allowance of 1.15 for
water and 1.333 for steam. For installations having unusual piping and pick-up
requirements, additional allowance should be made before selecting the boiler.
Model
TR 30
TR 40
TR 50
kg
217
257
305
lbs.
479
566
673
kg
221
261
309
lbs.
488
575
682
kg
215
254
295
lbs.
473
559
651
kg
224
263
304
lbs.
483
579
671
P PT PZ PZT
Rectangular
I.D. × Height
n × n × ft
mm × mm × m
8"×12"×15'
203×305×
4.6m
8"×8"×15'
203×203
×4.6m
7"×15'
178×4.6m
CAUTION: NEVER BURN GARBAGE OR
PAPER IN THE BOILER
AND NEVER LEAVE COMBUSTIBLE
MATERIAL ON OR AROUND IT.
