QUICK START
22
see the model number briefly appear on the LED readout as well as the firmware version
number and then clear itself.
F). If the instrument DEFAULTS are acceptable, then be sure to connect the appropriate
test leads to the device under test (DUT) or test fixture. Be certain that the unit is
connected to suitable power with a known good ground before energizing this instrument,
then connect the return lead first (black) to the test fixture or item followed by the high
voltage output lead (red).
G). Please check your connections to be sure they are making good
contact and that the test station or area is clear of debris and other
personnel. DO NOT TOUCH THE DEVICE UNDER TEST ONCE THE TEST HAS
BEEN STARTED. To initiate the test press the GREEN test button on the front panel.
This is a momentary button. The instrument will then cycle ON and begin the automated
test using the defaults. If a failure occurs you will HEAR an audible alarm go off. To
stop the alarm you must depress the RED button marked RESET. This will silence the
alarm and reset the instrument to begin another test. This RESET button can also be used
to ABORT a test and cut off the HIGH VOLTAGE.
When HIGH VOLTAGE is present a RED flashing High Voltage LED indicator located
to the right of the display will remain flashing until the HIGH VOLTAGE is OFF. Once a
test has ended, the Discharge LED indicator illuminates to notify you of any voltage
stored in the DUT. This LED will be RED if the voltage is greater than 30 Volts, and
GREEN if the voltage is less than 30 volts. You should wait until this LED is green before
touching the DUT or removing the test leads. If the device under test PASSED the test,
then no audible alarm will sound. In the case of a FAIL condition the instrument will
provide a visual and audible alarm. Pressing the reset button will reset the instrument
alarm.
WARNING
