QUICK START
21
QUICK START
This quick start guide presumes the operator has some familiarity with hipot testing and
desires to use the "default" settings on the instrument. The default settings shown will
remain in memory unless you choose to override them with your own test program. The
instrument default settings are as follows:
DEFAULTS
• Input Voltage: 115 or 230 volts AC, country specific
(rear-panel switch selectable)
• Resistance Lo-Limit: 0.1 megohms
• Voltage Output: 500 V
• Delay: 1 (1 second)
• Dwell: 1 (1 second)
A). Unpack this instrument from its special shipping container. Be sure to save all
packaging materials in case you need to return it to the factory for service.
B). Connect the provided 9-pin “D” type plug to the mating connector on the back panel
of the tester. This plug includes a jumper for the safety interlock. This plug must be
connected for the tester to operate.
C). Locate a suitable testing area and be sure you have read all safety instructions for the
operation of the instrument and suggestions on the test area set-up in the SAFETY section
of this manual. Locate a three prong grounded outlet. Be sure the outlet has been tested
for proper wiring before connecting the instrument to it.
D). Check to be sure the correct input line voltage has been selected
on the rear panel. Either 115 volts AC or 230 volts AC. Connect the
power input plug into its socket on the rear panel of the instrument. Connect the male end
of the plug to the outlet receptacle.
E). Turn on the POWER switch located on the lower left hand side of the front panel.
Upon powering the instrument up a POWER ON SELF TEST (POST) will automatically
be performed. This test will check for the condition of all critical components. You will
CAUTION
