INTRODUCTION
10
Although the IR test can be a predictor of insulation condition, it does not replace the
need to perform a Dielectric Withstand test.
TYPES OF FAILURES DETECTABLE ONLY WITH A HIPOT TEST
• Weak Insulating Materials
• Pinholes in Insulation
• Inadequate Spacing of Components
• Pinched Insulation
SERVICE AND MAINTENANCE
User Service
To prevent electric shock do not remove the instrument cover. There are no user
serviceable parts inside. Routine maintenance or cleaning of internal parts is not
necessary. Any external cleaning should be done with a clean dry or slightly damp cloth.
Avoid the use of cleaning agents or chemicals to prevent any foreign liquid from entering
the cabinet through ventilation holes or damaging controls and switches, also some
chemicals may damage plastic parts or lettering. Schematics, when provided, are for
reference only. Any replacement cables and high voltage components should be acquired
directly from Slaughter Company. Refer servicing to a Slaughter Company authorized
service center.
SLAUGHTER COMPANY, INC.
28105 N. KEITH DRIVE
LAKE FOREST, IL 60045-4546 U.S.A.
(PHONE: 1 (847) 932-3662
1 (800) 504-0055
FAX: 1 (847) 932-3665
E-MAIL : support@hipot.com
www.hipot.com
Service Interval
The instrument and its power cord, test leads, and accessories must be returned at least
once a year to a Slaughter Company authorized service center for calibration and
inspection of safety related components. Slaughter Company will not be held liable for
injuries suffered if the instrument is not returned for its annual safety check and maintained
properly.
User Modifications
Unauthorized user modifications will void your warranty. Slaughter Company will not be
responsible for any injuries sustained due to unauthorized equipment modifications or use
of parts not specified by Slaughter Company. Instruments returned to Slaughter Company
with unsafe modifications will be returned to their original operating condition at your
expense.
