FY301 – Operation, Maintenance and Instructions Manual
1.12
Recommendations for mounting Approved Equipments with the IP 66 W
certifications (use in saline atmospheres)
NOTE
This certification is valid for stainless steel positioners manufactured,
certification IP 66 W. All positioner external material, such as gauge, plugs, connections etc.,
should be made in stainless steel.
The electrical connection with 1/2” – 14NPT thread must use waterproofing sealant. A non-
hardening silicone sealant is recommended.
The instrum
ent modification or replacement parts supplied by other than authorized
representative of Smar is prohibited and will void the certification.
Rotary and Linear Magnet
Magnet models are linear and rotary, for utilization on linear and rotary actuators.
Figure 1.15 – Linear and Rotary Magnet Models
