SMAR FY301 - Accessories; Spare Parts List

H[523"⁄"Qrgtcvkqp."Ockpvgpcpeg"cpf"Kpuvtwevkqpu"Ocpwcn"
7032"
Ceeguuqtkgu"
"
ACCESSORIES
ORDERING CODE DESCRIPTION
SD-1
Magnetic tool for local adjustment.
HPC401*
Hart® HPI311-M5P for the PalmOS platform, including the configuration package for the Smar and generic
transmitters.
HPI311-M5P*
Just the Hart® interface.
400-0726
Needle cleaning device for the restriction.
* For equipment updates and HPC401 software, just check: http://www.smarresearch.com .
Urctg"Rctvu"Nkuv"
SPARE PARTS LIST
PARTS DESCRIPTION POSITION CÓDE
CATEGORY
(NOTE 4)
HOUSING (NOTE 1)
COVER (INCLUDES O-RING)
Cover Locking Bolt
Sensor Locking Bolt (M6 Without Head Screw)
External Ground Bolt
Identification Plate Fixing Bolt
Orings Cover (NOTE 2)
Local Adjustment Protection Cover
8
1 and 13
6
7
14
9
2
10
400-1314-3 (NOTE 6)
400-1307 (NOTE 6)
204-0120
400-1121
204-0124
204-0116
204-0122
204-0114
-
-
-
-
-
-
B
-
DIGITAL INDICATOR GLL1438 (for old electronic main board GLL1011)
DIGITAL INDICATOR (for new main boards GLL1443 e 1451)
4
400-1305
400-1310
A
TERMINAL INSULATOR
TERMINAL INSULATOR FOR 4-20mA POSITION FEEDBACK (packaged
with 6 units) (NOTE 7)
11
400-0058
400-1329
A
MAIN ELECTRONIC CIRCUIT BOARD (include digital indicator and
mounting kit)
5 400-1334 A
TERMINAL HOLDING BOLT HOUSING
MOUNTING KIT FOR MAIN ELECTRONIC BOARD (new boards GLL1443
and 1451), (2 bolts with spacers and retention washers)
12
3
204-0119
400-0560
B
B
CONNECTION COVER
. Connection Cover Bolt
. Buna-N Neck O-ring (NOTE 2)
15,16 and 17
15
16
400-1320 (NOTE 6)
400-0073
204-0113
A
-
B
ANALOG BOARD without Pressure Sensor GLL1012 (version K0)
ANALOG BOARD for Pressure Sensor GLL1204 (version K1)
ANALOG BOARD for Position Feedback GLL1456 (version K2)
18
18
18
400-0060
400-0840
400-1341
-
-
-
PIEZO BASE SET
. Base and Block O-ring (NOTE 2)
. Restriction
. Restriction External O-ring (NOTE 2)
. Restriction Internal O-ring (NOTE 2)
. Syntherized Bushing
. Analog indicator (Gage - Stainless Steel and Brass) (NOTE 5)
19,20,21,22, 23,24 and 25
19
20
21
22
23
25
400-1318 (NOTE 6)
400-0085
344-0165
344-0155
344-0150
400-0033
400-1120
A
B
B
B
B
B
B
ASSEMBLED DIAPHRAGM (include hall tube, mechanical part and
O-rings)
27
400-1321 (NOTE 6)
B
