DETAILED CODE WHEN ORDERING OF SPARE PARTS
CÓDE DESCRIPTION
400-1316 Transducer Set; FY30X
Option Indication Gage
0
Without Gage
6
01 Gage - Input
7
01 Gage – Output 1
8
02 Gage – Input and Output 1
9
02 Gage – Output 1 and 2
A
03 Gage
Option Action of Positioner
C
Single Action
D
Double Action
Option Material
H0
Aluminum (IP/TYPE)
H1
Stainless Steel (IP/TYPE)
Option Painting
P0
Gray Munsell N 6,5
P8
Without Painting
P9
Safety Blue Epoxy - Electrostatic Painting
Option Standard of Manufacture
S0
Smar
Option Hall Remote Sensor
R0
Standard Mounting (Without Hall Remote Sensor)
R9
Remote Mounting (adapted for Remote Sensor)
Option Special Sensor
K0
Without Special Sensor (compatible w/ main board until version 4)
K1
With Pressure Sensors for Diagnostic (compatible w/ main board
until version 3)
K2
With 4-20mA Position Feedback (compatible w/ main board version 5
)
400-1316 * * * * * * * TYPICAL ORDERING CODE
* Choose the desired option.
DETAILED CODE WHEN ORDERING OF SPARE PARTS
CÓDE DESCRIPTION
400-1317 Pneumatic Block Set; FY30X
Option Indication Gage
0
Without Gage
7
01 Gage – Output 1
9
02 Gage – Output 1 and 2
Option Action of Positioner
C
Single Action
D
Double Action
Option Material
H0
Aluminum (IP/TYPE)
H1
Stainless Steel (IP/TYPE)
Option Painting
P0
Gray Munsell N 6,5
P8
Without Painting
P9
Safety Blue Epoxy - Electrostatic Painting
Option Standard of Manufacture
S0
Smar
Option Special Sensor
K0
Without Special Sensor
K1
With Pressure Sensor for Diagnostic (compatible w/ main board version 3,
besides analog board GLL1204)
400-1317 * * * * * * TYPICAL ORDERING CODE
