4. Preparation (continued)
Contents
4.4 Preparing the STR (continued)
4.4.3 Connection Kit (D1 only) (continued)
Fig. 4.4.3.5 Fig. 4.4.3.6
Step
Action
Remarks
4.
Connection kit.
Unpack mounting hardware (Fig. 4.4.3.5).
5.
Identify parts.
D = Hex tap bolt M12*50 (2x)
E = Flat Lock Washer M12 Ø 37mm (2x)
F= Adjusting Ring M12*22*12 (2x)
G = Flat Lock Washer M12 Ø 24mm (optional usage).(8x)
(Fig. 4.4.3.6).
D
E
F
G
B
C
