5. Installation (continued)
Contents
5.1 Mechanical Installation (continued)
5.1.4. Belt Stacker on STR
Fig. 5.1.4.1 Fig. 5.1.4.2
Fig. 5.1.4.3 Fig. 5.1.4.4
Step
Action
Remarks
1.
Check Lower Outfeed
Roller position.
For Belt Stacker on STR this Roller should be in the low position.
Correct if necessary. (Figs. 5.1.4.1 – 5.1.4.4.)
