Smart Dedicated Design STR7202 - Page 45

Installation Manual STR7202 TAG4 & SFM7704 TAG1
DBCI-0512-0052-V013
STR7202 2-Side Trimmer & SFM7704 Square Fold Module
Name: RI01
Date: 29-3-2017
Page: 45 / 72
5. Installation (continued)
Contents
5.2. Electrical Installation (continued)
5.2.3 Installing Start/Stop Interface in Canon Booklet Trimmer F1 (continued)
Fig. 5.2.3.5 Fig. 5.2.3.6
Fig. 5.2.3.7 Fig. 5.2.3.8
Step
Action
Remarks
4.
Unpack cables
Unpack Cablekit OGEO-0000-0091-0000 (Fig. 5.2.3.5).
5.
Identify required parts
• F1 Start/Stop Interface Cable – Fig. 5.2.3.6
• F1 Replacement Rear Cover – Fig. 5.2.3.7
• Communication Cable – Fig. 5.2.3.8
NOTE
Note F1 Labels
