5. Installation (continued)
Contents
5.2. Electrical Installation (continued)
5.2.4 Installing Start/Stop Interface in Canon D1 (continued)
Fig. 5.2.4.5 Fig. 5.2.4.6
Fig. 5.2.4.7 Fig. 5.2.4.8
Step
Action
Remarks
4.
Unpack cables
Unpack Cablekit OGEO-0000-0091-0000 (Fig. 5.2.4.5).
5. Identify required parts
• D1 Start/Stop Interface Cable – Fig. 5.2.4.6
• D1 Replacement Rear Cover – Fig. 5.2.4.7
•
Communication Cable – Fig. 5.2.4.8
NOTE
Note D1 Labels
