Installation Manual STR7202 TAG4 & SFM7704 TAG1
DBCI-0512-0052-V013
STR7202 2-Side Trimmer & SFM7704 Square Fold Module
Name: RI01
Date: 29-3-2017
Page: 53 / 72
5. Installation (continued)
Contents
5.2. Electrical Installation (continued)
5.2.4 Installing Start/Stop Interface in Canon D1 (continued)
Fig. 5.2.4.17
Step
Action
Remarks
11.
Mount Replacement cover
Place Grommet for Communication Cable in slot in D1
Replacement Cover and mount on the D1 Rear Cover
(Fig. 5.2.4.17).
