Smart Dedicated Design STR7202 - Page 57

Installation Manual STR7202 TAG4 & SFM7704 TAG1
DBCI-0512-0052-V013
STR7202 2-Side Trimmer & SFM7704 Square Fold Module
Name: RI01
Date: 29-3-2017
Page: 57 / 72
5. Installation (continued)
Contents
5.2. Electrical Installation (continued)
5.2.7 Connecting Belt Stacker to STR
Fig. 5.2.7.1
Step
Action
Remarks
5.
Connect Belt Stacker
Communication Cable.
Connect the Communication cable of the Belt Stacker to
J12 (A) on the STR (Fig. 5.2.7.1)
A
