hidden/displayed and its speed unit
selected (Y page 159).
Outside temperature display
You should pay special attention to road
conditions when temperatures are around
the freezing point.
Bear in mind that the outside temperature
display indicates the temperature meas-
ured and does not record the road temper-
ature.
The display
shows the outside temperature
on the far right in the header:
R
monochrome display (Y page 151)
R
colour display (Y page 153)
Changes in the outside temperature are
displayed after a short delay.
If the outside temperature has fallen below
3 †, the Ò symbol is shown beside the
outside temperature display.
At outside temperatures between -3 †and
3 †:
R
the Ã’ symbol flashes for about
1 minute in the monochrome display and
then remains on continuously.
R
the colour display also shows a display
message next to the Ã’ symbol
(Y page 173).
For an on-board computer with colour dis-
play, you can set the temperature unit of the
outside temperature display (Y page 160).
Fuel gauge
Fuel level indicator (example: monochrome dis-
play)
Fuel level indicator (example: colour display)
:
Reserve fuel display
;
Fuel gauge
=
Fuel filler flap location indicator
u The fuel filler cap is located on
the right
?
6 Reserve fuel (yellow)
Fuel gauge ; is shown in the display as a
segment display with eight segments.
When
the fuel level falls below the reserve
range of 5.0 l, the last illuminated segment
of the fuel display will flash and a warning
tone will sound. Reserve fuel display :
will also appear. The reserve fuel display
shows the numeric value of the remaining
fuel level in 0.5 l increments.
With a colour display:
R
6 symbol ? also appears in yellow
R
a display message is also shown
(Y page 175).
Displays and operation
149
