Insert the One Dial electrical
junction box into the tile. Press
on the box until the outer
setting touches the tile.
CAUTION
THE CONTROLLER
LOCK MECHANISM
ON THE SETTING
(IMAGE) SHOULD BE
PARALLEL TO THE
FRAME OF THE TILE.
Attach the One Dial junction
box to the tile with silicone/glue
from the inside.
Apply a thick layer of
compound to fully seal
the internal components.
Insert the junction box
Seal the junction box
