SmarTap e-Valve - Technical Specifications

7 of 51
Technical Specifications
Absolute Maximum Ratings
Working pressure
1 – 9 bar
Overpressure
16 bar
Burst pressure
35 bar
Hot water temperature
70 C
o
Ambient temperature
5 – 60 C
o
Relative humidity
90% non-condensing
Recommended Conditions
Working pressure
2 – 5 bar
Hot water temperature
50 – 65
o
C
Cold water temperature
10 – 25
o
C
Set point temperature
Cold water or 35 – 45
o
C
Performance at Recommended Conditions
Temperature accuracy
±0.5°C
Flow accuracy
±5% of Full Scale
Hydraulic performance
Complies with EN1111 standard
Miscellaneous
Supplied user interface
cable length
9m
Operational voltage
100 – 240V ~ 50 – 60Hz
Standards
Safety: EN 60335-1 :2012,
EN60335-2-105:2005
EMC: EN 55014-1, EN 55014-2
CE, RoHS, WRAS
WARNING
DO NOT USE THE SYSTEM IF THESE CONDITIONS
ARE NOT MET.
