1. Insert the cable into the e-Vale through the cable inlet holes on
the sides of the e-Valve.
2. Gently connect the cable connector to an applicable interface on
the main module. To do so, align the projection of the cable’s
connector to the receptacle keyway slot of the interface.
WARNING
THERE IS ONLY ONE WAY TO CONNECT EACH CABLE.
MAKE SURE THAT THE CABLE CONNECTOR IS FULLY
INSERTED INTO THE INTEFACE.
3. Screw connector closed to finger tightness. NO TOOLS
NEEDED.
Connect cables
