Smartgen HGM1780 User Manual

HGM1780 Automatic Genset Controller
ISSUE 2013-04-03
Version1.7
Page 18 of 24
HGM1780 Automatic Genset Controller
6.4 SENSOR SELECTION (TABLE 4)
Items
Content
Remark
Temperature
Sensor
0 Not used
1 Digital closed
2 Digital open
3 User defined resistor type
4 VDO
5 SGH (yellow river sensor)
6 SGD (Dongkang sensor )
7 CURTIS
8 DATCON
9 VOLVO-EC
10 SGX 120 DEGREE
Digital closed and Digital open
both are digital signal; low or high
electrical level can be selected to
be active, connecting to earth
point will mean that low electrical
level is selected, hang in air
means high electrical level is
selected; can not be connected to
power supply positive.
The range of user-defined resistor
type sensor is 0-999.9 Ohm, by
default SGD sensor is selected.
Oil pressure
Sensor
0 Not used
1 Digital closed
2 Digital open
3 User defined resistor type
4 VDO
5 SGH (yellow river sensor)
6 SGD(Dongkang sensor )
7 CURTIS
8 DATCON 10Bar
9 VOLVO-EC
10 SGX 10Bar
Digital closed and Digital open
both are digital signal; low or high
electrical level can be selected to
be active, connecting to earth
point will mean that low electrical
level is selected, hang in air
means high electrical level is
selected; can not be connected to
power supply positive.
The range of user-defined resistor
type sensor is 0-999.9 Ohm, by
default SGD sensor is selected.
Fuel Level
Sensor
0 Not used
1 Digital closed
2 Digital open
3 User defined resistor type
4 SGH (yellow river sensor)
5 SGD (Dongkang sensor )
6 Reserved 1
7 Reserved 2
Digital closed and Digital open
both are digital signal; low or high
electrical level can be selected to
be active, connecting to earth
point will mean that low electrical
level is selected, hang in air
means high electrical level is
selected; can not be connected to
power supply positive.
The range of user-defined resistor
type sensor is 0-999.9 Ohm, by
default “Not used” is selected
Before selecting fuel level sensor
type, digital input type must be set
as 0.
