7.
PARAMETER SETTING
1)
Pressing
and
simultaneously in generator standby mode will lead to the
password interface (as shown below); when the first digit is blinking, enter the
password 0318;
2)
Press button to increase the value of the blinking digit and to decrease
the value; when the first digit is set, press
to move the cursor;
3)
Repeat the same procedure to set the digits from 2
nd
to 4
th
;
4)
If the password is right, enter into the parameter configuration interface (as shown
below) which including the serial number of the set items and their parameters;
press to scroll up and to scroll down;
5)
Press to set the current item, and when the first digit starts blinking, use the
same way that is used for password to enter the set value.
Password: Parameter Setting:
Attention:
1)
Please change the controller parameters when generator is in standby mode only (e.
g. Crank disconnect conditions selection, configurable input, configurable output,
various delay), otherwise, shutdown and other abnormal conditions may happen.
2)
The value of each parameter can be set only within a certain range.
3)
Over voltage set value must be higher than under voltage set value, otherwise
over voltage and under voltage condition may occur simultaneously.
4)
Over speed set value must be higher than under speed set value, otherwise over
speed and under speed condition may occur simultaneously.
5)
Please set the generator frequency value as low as possible when cranking, in
order to make the starter be separated quickly as soon as crank disconnect.
6)
Consult the table 1 for serial numbers of the parameters.
7)
Before selecting fuel level sensor type, it is necessary to set a configurable input
port type as 0.
