HGM400N Series Genset Controller User Manual Page 21 of 38
No.
Items
Range
Default
Description
table 8.
43
Aux. Output 2
(0-23)
2
Factory default: Energized to Stop. Details see
table 8.
44
Aux. Output 3
(0-23)
3
Factory default: Idle Control. Details see table
8.
45
Aux. Output 4
(0-23)
5
Factory default: Close Generator. Details see
table 8.
46
Aux. Output 5
(0-23)
6
Factory default: Mains Closed. Details see
table 8.
47
Digital Input 1
(0-19)
1
Factory default: High Temperature Input.
Details see table 9.
48
Digital Input 1 Active
(0-1)
0
Factory default: Close to active.
49
Digital Input 1 Delay
(0-20.0)s
2.0
50
Digital Input 2
(0-19)
2
Factory default: Low Oil Pressure Alarm Input.
Details see table 9.
51
Digital Input 2 Active
(0-1)
0
Factory default: Close to active.
52
Digital Input 2 Delay
(0-20.0)s
2.0
53
Digital Input 3
(0-19)
10
Factory default: Remote Start. Details see table
9.
54
Digital Input 3 Active
(0-1)
0
Factory default: Close to active.
55
Digital Input 3 Delay
(0-20.0)s
2.0
56
Digital Input 4
(0-19)
11
Factory default: Fuel Level Warn Input. Details
see table 9.
57
Digital Input 4 Active
(0-1)
0
Factory default: Close to active.
58
Digital Input 4 Delay
(0-20.0)s
2.0
59
Power On Mode
(0-2)
0
0: Stop Mode
1: Manual Mode
2: Auto Mode
60
Module Address
(1-254)
1
Communication address of controller.
61
Passwords
(0-9999)
0318
Please see NOTE 6 for details.
62
Crank Disconnect
(0-6)
2
There are 3 conditions of disconnecting starter
with engine: Generator Frequency, Magnetic
Pickup, Oil Pressure. Each condition can be
used alone and simultaneously to separating
the start motor and genset as soon as
possible.
63
Disconnect Magnetic
Pickup
(0-6000)r/min
360
When engine speed is higher than the set
value, starter will be disconnected.
64
Disconnect Gen Freq
(10.0-30.0)Hz
14.0
When generator frequency is higher than the
set value, starter will be disconnected.
65
Disconnect OP
(0-400)kPa
200
When generator oil pressure is higher than the
set value, starter will be disconnected.
