HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 6 of 44
2 PERFORMANCE AND CHARACTERISTICS
 HGM400 series controller has two types:
HGM410: ASM (Automatic Start Module)，it controls generator to start/stop by
remote signal;
HGM420: AMF (Auto Mains Failure), updates based on HGM410, moreover, has
mains electric quantity monitoring and mains/generator automatic transfer control
function, especially for automatic system composed by generator and mains.
 132x64 LCD with backlight, selectable language interface (Chinese, English,
Spanish, Turkish and Russian), push-button operation;
 Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase
3-wire systems with voltage 120/240V and frequency 50/60Hz;
 Collects and shows 3-phase voltage, current, power parameter and frequency of
generator or mains.
Mains Generator
Line Voltage (Uab, Ubc, Uca) Line Voltage (Uab, Ubc, Uca)
Phase Voltage (Ua, Ub, Uc) Phase Voltage (Ua, Ub, Uc)
Frequency (HZ) Frequency (HZ)
Load
Current (IA, IB, IC)
Active Power (KW)
Reactive Power (KVar)
Apparent Power (KVA)
Power Factor (PF)
Accumulated Energy (kWh)
 For Mains, controller has over voltage, under voltage and loss of phase detection
functions; For generator, controller has over voltage, under voltage, over frequency,
under frequency and over current detection functions;
 Precision collect and display parameters about Engine,
Temp. (WT) °C/°F both be displayed
Oil pressure (OP) kPa/Psi/Bar all be displayed
