1) There are 3 kinds of crank disconnect conditions. Speed, Generator frequency and Oil pressure can
be used alone. Oil pressure used with speed and generator frequency together is recommended, in
order to make the starter and the engine disconnect as soon as possible.
2) Speed is the signal measured by magnetic sensor, which is installed in the engine for testing
flywheel teeth.
3) When choosing speed, ensure the number of flywheel teeth is same as the pre-set, otherwise over
or under speed shutdown may appear.
4) If generator has no magnetic pickup sensor, don't choose speed item; otherwise Fail to Start or
Loss of Speed Signal shutdown will occur.
5) If the generator has no oil pressure sensor, don't choose corresponding item.
6) If generator frequency has not been selected, controller will not measure and display the relative
parameters (can be applied to the pump set); if speed has not been selected, the speed will be
calculated by the generating AC signal.
8 PARAMETER SETTING
After controller powered on, press to enter into the parameters setting menu:
1) Parameters Setting
2) Information
3) Language
4) Event Log
5) Maintenance Setting
— Parameters Setting
“0318” can set all items in table 7 during inputting password. When default password has been
changed, it needs to input the same password with controller for parameter setting via PC software.
If more parameter items need to be set or password is forgotten, such as voltage and current
calibration, please contact the factory.
NOTES:
1) HGM6110, there are no items 1-5 in table 7; programmable output 1-4 have no digital outputs
about mains.
2) Please modify the parameters in standby mode (crank conditions, auxiliary input and output
