Smartgen HGM6120NC - Perkins; Scania; Volvo EDC3

HGM6100N Series Genset Controller User Manual Page 44 of 47
13.13 PERKINS
It is suitable for ADEM3/ ADEM4 engine control mode. Engine type is 2306, 2506, 1106, and 2806.
Table 32 – Connector
Terminals of controller
Connector
Remark
Configurable output 1
1, 10, 15, 33, 34
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
-
Connect to starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
31
Using impedance 120Ω connecting line.
CAN(L)
32
Using impedance 120Ω connecting line.
Engine type: Perkins.
13.14 SCANIA
It is suitable for S6 engine control mode. Engine type is DC9, DC12, and DC16.
Table 33 – B1 Connector
Terminals of controller
B1 connector
Remark
Configurable output 1
3
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
-
Connect to starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
9
Using impedance 120Ω connecting line.
CAN(L)
10
Using impedance 120Ω connecting line.
Engine type: Scania.
13.15 VOLVO EDC3
Suitable engine control mode is TAD1240, TAD1241, and TAD1242.
Table 34 – “Stand alone” Connector
Terminals of controller
“Stand alone” connector
Remark
Configurable output 1
H
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
E
Configurable output 2
P
ECU power;
Set configurable output 2 as “ECU power”.
Table 35 – “Data bus” Connector
Terminals of controller
“Data bus” connector
Remark
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1
Using impedance 120Ω connecting line.
CAN(L)
2
Using impedance 120Ω connecting line.
