Engine type: Volvo.
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
13.16 VOLVO EDC4
Suitable engine types are TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722, and
TAD732.
Table 36 – Connector
Terminals of controller
Connector
Remark
Configurable output 1
Expanded 30A relay, and
relay offers battery voltage
to terminal 14. Fuse is 16A
Set configurable output 1 as “Fuel Relay
Output”.
Starting relay output
-
Connect to starter coil directly.
1
Connected to negative of battery.
CAN GND
-
CAN communication shielding line.
CAN(H)
12
Using impedance 120Ω connecting line.
CAN(L)
13
Using impedance 120Ω connecting line.
Engine type: VolvoEDC4.
13.17 VOLVO-EMS2
Volvo Engine types are TAD734, TAD940, TAD941, TAD1640, TAD1641, and TAD1642.
Table 37 – Engine CAN Port
Terminals of controller
Engine’s CAN port
Remark
Configurable output 1
6
ECU stop;
Configurable output 1 “ECU stop”.
Configurable output 2
5
ECU power;
Configurable output 2 “ECU power”.
3
Negative power.
4
Positive power.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1(Hi)
Using impedance 120Ω connecting line.
CAN(L)
2(Lo)
Using impedance 120Ω connecting line.
Engine type: Volvo-EMS2.
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
