ICON Lamp Dimmer User’s Guide
Page 12 of 18
ADVANCED X10 PROGRAMMING OPTIONS
You can remotely set up X10 On-Levels using an X10 Controller capable of sending an X10 address
(house code and unit code) without sending X10 ON or OFF commands. The following procedures will
not work with a transmitter that sends the X10 address and an X10 command together. X10 Controllers
in which one button is pressed to turn an X10 device on or off WILL NOT WORK.
These procedures all begin by sending the same sequence of five X10 addresses, called the CLEAR
Sequence. After you send the CLEAR Sequence, you have about 4 minutes to finish the procedure
before automatic timeout.
Remotely Setting the On-Level for the X10 Primary Address
The On-Level you set using this method will take effect immediately for the X10 Primary Address, but this
On-Level will not take effect for INSTEON until you link (or re-link) ICON Lamp Dimmer with an INSTEON
Controller.
1. Using an X10 Controller, send the CLEAR Sequence:
2. Send the X10 Primary Address (house code and unit code).
3. Set the On-Level for the X10 Primary Address by adjusting ICON Lamp Dimmer’s brightness using
any Controller. If you skip this step, the current On-Level will be used.
4. Send the following X10 Address sequence to lock in the new On-Level:
5. ICON Lamp Dimmer will flash the lamp it is controlling and blink its Status LED, indicating that the
On-Level has been set for the X10 Primary Address.
.
O16 N16 M16 P16 M16
P16 N16 M16 O16 M16
