ICON Lamp Dimmer User’s Guide
Page 6 of 18
Unlinking ICON Lamp Dimmer from an INSTEON Controller
If you are no longer going to use an ICON Lamp Dimmer that has previously been linked to an INSTEON
Controller, it is very important that you unlink it, because otherwise the controller will retry any commands
intended for the unused module, thus slowing down your system.
1. Select your INSTEON Controller from the list below and follow the method shown to put it into
Unlinking Mode.
A. ICON Dimmer Switch – Press and hold ICON Dimmer Switch’s Paddle Top for 10
seconds TWICE. To confirm that it is in Unlinking Mode, ICON Dimmer Switch will
flash the light that it is wired to once for each paddle press and begin blinking its LED.
B. ICON Tabletop Controller – Press and hold the OFF Button of the ON/OFF Button
Pair you used for controlling ICON Lamp Dimmer for 10 seconds. To confirm that it is
in Unlinking Mode, ICON Tabletop Controller’s Status LED will begin blinking.
C. ICON Keypad Dimmer– Press and hold for 10 seconds the Button you used for
controlling ICON Lamp Dimmer, then press and hold the same Button for 10 seconds
again. To confirm that it is in Unlinking Mode, ICON Keypad Dimmer will flash the
light that it is wired to once and begin blinking the ON Button that you pushed.
D. Other INSTEON Controllers – See the INSTEON Controller’s User’s Guide.
2. Press and hold the black SET Button on ICON Lamp Dimmer for 3
seconds. Both the lamp you are controlling and ICON Lamp
Dimmer’s Status LED will blink to confirm unlinking. Depending on
the INSTEON Controller, you have about 4 minutes to perform this
step before Unlinking Mode times out automatically.
