ICON Lamp Dimmer User’s Guide
Page 7 of 18
HOW TO SET UP ON-LEVELS (Optional)
The On-Level is the brightness that the lamp you are controlling will go to when you turn it on using an
INSTEON Controller. The On-Level is adjustable from OFF to 100% brightness. The default is 100%.
1. Using the ON/OFF Button Pair that you already linked ICON Lamp Dimmer to, set the INSTEON
Controller to Linking Mode by pressing and holding the ON Button of the pair for 10 seconds.
2. Using the BRIGHT or DIM Buttons on the INSTEON Controller, adjust the brightness of the lamp
you are controlling to the desired On-Level and tap the SET Button on ICON Lamp Dimmer ONCE.
3. Press and hold the black SET Button on ICON Lamp Dimmer for
3 seconds. Both the lamp you are controlling and ICON Lamp
Dimmer’s Status LED will blink to confirm the On-Level setting.
