ICON Lamp Dimmer User’s Guide
Page 17 of 18
SPECIFICATIONS
ICON Lamp Dimmer Specifications
General
ICON Product Number 2856D2/2856D2B, ICON Lamp Dimmer
Warranty 1 year
Operation
Status LED Green
On-Levels 32
Local Control Load sensing (can be disabled)
Setup Memory Non-volatile EEPROM
INSTEON Features
INSTEON Addresses 1 hard-coded out of 16,777,216 possible
INSTEON Links 30
INSTEON Powerline Frequency 131.65 KHz
INSTEON Minimum Transmit Level 3.2 V
pp
into 5 Ohms
INSTEON Minimum Receive Level 1 mV
pp
nominal
INSTEON Messages Repeated Yes
X10 Features
X10 Primary Address 1 optional (comes unassigned)
X10 Scene Addresses N/A
X10 Status Response Supported
X10 Resume Dim Supported (by setting X10 Primary Address On-Level to zero)
X10 Powerline Frequency 120 KHz
X10 Minimum Transmit Level 3.2 V
pp
into 5 Ohms
X10 Minimum Receive Level 10 mV
pp
nominal
X10 Messages Repeated No
Mechanical
Operating Conditions Indoors, 32 to 122°F, up to 85% relative humidity
Dimensions 4.0” H x 2.5” W x 1.5” D
Weight 5 oz
Electrical
Supply Voltage 120 Volts AC +/- 10%, 60 Hertz, single phase
Surge Protection MOV rated for 150 Volts
Power Plug 2-pin polarized
Controlled Outlet 2-pin polarized
Load Types Plug-in incandescent lighting devices
Maximum Load 150 Watts
Minimum Load 25 watts (for Local Control load sensing)
Certification Safety tested for use in USA and Canada (ETL #3017581)
