SmarTrike Xtend Mg+ - Page 22

-22-
5
Step 5:
Step 6:
B
A
Click
Click
C
B-C. Cover the chain with the lid Until you hear a “click”.
6
Tighten the screws so the pedal
system can be locked to the body.
Do not throw
6mm / 0.23’’
5mm / 0.2‘’
A. Remove the screw and keep it
aside.
