Hydro:Evolved Start-Up Guide
Page 12 ©2022 Smartrise Engineering, Inc. All Rights Reserved Jul 14, 2022
7 Hydro Speed Setup
The Hydro Speed Setup takes the slowdown factor of the distance and time relative to the
speed to generate the slowdown distances and threshold for each landing. The up and down
adjustments depend upon the selected factor in which the greater the factor the greater the
distance. For example, if the factor is 1 second, the slowdown distance will be 2’ 1” where as if
the factor is 1.78 seconds, the slowdown distance will be 3’ 8”. Depending upon the high speed
and type of valve setup, the factor can be determined.
To have a proper slowdown for up or down direction, adjust the up and down time.
Note: Changes made on Up Adjustment and Down Adjustment will not take affect while
Adaptive Slowdown™ system (U.S. Patent Pending) is active, turn off Adaptive Slowdown™
system (U.S. Patent Pending) before proceeding.
Navigate to MAIN MENU | SETUP | HYDRO | HYDRO SPEED SETUP | UP and DOWN
ADJUSTMENT (need to set both).
Adjust the time to set the distance the car will begin slowing down from high speed to
leveling speed in the Up Distance and Down Distance
Scroll back to GENERATE THRESHOLDS AND DISTANCES and select YES. If YES is not
selected, new thresholds and slowdowns are not generated.
Selecting yes will generate the values for slowdown distance up, slow down distance
down, and threshold.
a. if overshooting occurs, following instructions on for Car Overshooting and repeat
step 1-4.
