Hydro:Evolved Start-Up Guide
Page 2 ©2022 Smartrise Engineering, Inc. All Rights Reserved Jul 14, 2022
The following is a graphical image of the parameters that are being adjusted:
0
50
100
150
200
250
300
350
400
450
0 2 4 6 8 10 12 14 16
0
50
100
150
200
250
300
350
400
450
0 2 4 6 8 10 12 14 16
A
]
B
D
F
E
C
LEGEND
A = Acceleration Rate
B = High Contract Speed
C = NTS Buffer Distance
D =Deceleration Rate
E = Leveling Time
F = Destination Offset
G = Slowdown Distance
H = TSRD Distance
G
H
Times (Seconds)
High and Low
Valves On
High Valve
Cut Off
Low Valve
Cut Off
Destination
High and Low
Valves On
High Valve
Cut Off
Low Valve
Cut Off
Destination
Velocity
(FPM)
Velocity
(FPM)
