I
NSTALLING
THE
S
WITCH
8
Verifying Port Status
The front panel of the switch provides status LEDs for “at-a-glance”
system monitoring. The following table details the functions of the various
indicators:
Verifying System Operation
Verify that all attached devices have a valid connection. The switch
monitors the link status for each port. If any device is properly
connected to the switch and transmitting a link signal, the port
Port and System Status LEDs
LED Condition Status
Power On The switch is receiving power.
Ports
Link/Act On The port has established a valid network
connection.
Off The port has not established any network
connection.
Flashing Traffic is passing through the port.
1000M On Indicates that the port is transmitting or
receiving data at 1000 Mbps.
Off No link up at 1000M.
10/100M On Indicates that the port is transmitting or
receiving data at 100 Mbps.
Off Indicates that the port is transmitting or
receiving data at 10 Mbps.
