-23-
No.D-※S-OMJ0004-E
Specifications
•D-M9B(E)(V)/D-M9N(E)(V)/D-M9P(E)(V)
PLC: Programmable Logic Controller
Switch part no.
D-M9N(E)
D-M9N(E)V
D-M9P(E)
D-M9P(E)V
D-M9B(E)
D-M9B(E)V
Wiring
3-wire
2-wire
Output
NPN
PNP
-
Lead wire
orientation
In line
Perpendicular
In line
Perpendicular
In line
Perpendicular
Applicable load
IC circuit/Relay/PLC
24 VDC Relay/PLC
Power supply
voltage
5/12/24 VDC (4.5 to 28 VDC)
-
Current
consumption
10 mA or less
-
Load voltage
28 VDC or less
-
24 VDC (10 to 28 VDC)
Load current
40 mA or less
2.5 to 40 mA
Internal voltage
drop
0.8 V or less at load current of 10 mA
(2 V or less at load current of 40 mA)
4 V or less
Current leakage
100 µA or less at 24 VDC
0.8 mA or less
Operating time
1 ms or less
Indication light
Normally open (normal direction) output:
When magnetic force is detected
The Red LED turns ON
Normally closed (inverted) output:
When magnetic force is not detected
Electrical entry
Grommet
Lead wire
Vinyl sheath cable
2.6, 0.15 mm
2
, 2-wire (D-M9B(E)(V)), 3-wire (D-M9N(E)(V),D-M9P(E)(V))
Impact proof
1000 m/s
2
Insulation
resistance
50 MΩ or more under the test voltage 500 VDC (between case and cable)
Withstand voltage
1000 VAC 1 min. (between case and cable)
Ambient
temperature
- 10 to 60 °C
Enclosure
IEC 60529 criteria IP67, JISC0920 watertight construction
