Display
Category
Mode
Indicator
light 2
Indicator
light 1
Description
System
status
Analogue
output
Current
output
Analogue current output active
Voltage
output
Analogue voltage output active
IO-Link
IO-Link connection active
Error
Sensor not ready for operation/
Detectable magnetic field is decrease
LED flashing at 4 Hz
Switch output
High
Switch output High
PNP: ON, NPN: OFF
Low
Switch output Low
PNP: OFF, NPN: ON
Over current error
Overload of the switch output
(over current)
Magnetic field
In measuring range
Magnetic field registered in measuring
range
Outside of measuring
range
Magnetic field is not registered in
measurement range
= LED ON, = LED flashing, = LED OFF
