-30-
No.D-※S-OMU0002-A
■Dimensions
(mm)
Model
A
B
Detectable range
D-MP025
40.5
25
D-MP050
64.9
50
D-MP100
114.9
100
D-MP200
214.7
200
D-MPB
D-MPC
Teach pad
Indicator light
Mounting thread
M8-4 pin connector
M12-4pin connector
D-MPA
