Specifications
Model
D-MP025
D-MP050
D-MP100
D-MP200
Measuring range
25 mm±1 mm
50 mm±1 mm
100 mm±1 mm
200 mm±1 mm
Power supply voltage
15 to 30 VDC, ripple (p-p) 10% or below
(with power supply polarity protection)
Current consumption
48 mA or less (when no load is applied)
Repeatability
1 2
0.1 mm (@25
o
C)
Resolution
0.05 mm
Linearity
2
±0.3 mm (@25
o
C)
Switch output
NPN or PNP 1 output (push-pull)
Max. load
current
40 mA
Internal voltage
drop
2 V or less
Leakage current
NPN: 0.5 mA or less at load resistance 3 kΩ,
1.5 mA or less at load resistance 750 Ω
PNP: 0.1 mA or less
Short circuit
protection
Yes
Analogue current
output
3
Output current
4 to 20 mA
Max. load
resistance
500 Ω
Analogue voltage
output
3
Output voltage
0 to 10 V
Min. load
resistance
2 kΩ
Lead wire
PUR 4 core 2.6 0.08 mm
2
Standards
CE marking (EMC directive • RoHS directive), UL
Impact resistance
300 m/s
2
Insulation resistance
50 MΩ or more with 500 VDC Ohmmeter
Withstand voltage
1000 VAC 1 minute
Ambient temperature
-10 to 60
o
C
Enclosure
IEC60529 IP67
IO-Link
Version
V1.1
Communication
speed
COM3 (230.4 kbps)
Min. cycle time
1 ms
Process data
size
Input: 2 byte, Output: 0 byte
Device ID
125 hex
126 hex
127 hex
128 hex
Vendor ID
83 hex
1: Repeatability of magnetic movement in one direction.
2: Varies depending on the operating conditions.
3: Switching between analogue voltage/current can be set.
