-8-
No.D-※S-OMU0002-A
Model Indication and How to Order
Summary of Product parts
○Summary of parts
Close up of operation display
D-MP
Mounting thread
Mounting thread
Teach pad
Mounting thread
Indicator light 1
Indicator light 2
Measuring range
Symbol
Content
025
25 mm
050
50 mm
100
100 mm
200
200 mm
Lead wire
Symbol
Content
A
2,000 mm
B
M8 4-pin, plug connector: 0.3 m
C
M12 4-pin A-coded, plug connector: 0.3 m
Class A
Operation display
