-49-
EX※※-OMR1012
Table. Settable range for user set upper or lower limit and Fault Value
User set output value
Settable range
Range
Lower limit Upper limit
Fault Value
Settable range
0..10 V 0.00 to +10.45 V +0.05 to +10.50 V 0.00 to +10.50 V
0..5 V 0.00 to +5.22 V +0.03 to +5.25 V 0.00 to +5.25 V
1..5 V +0.75 to +5.22 V +0.78 to +5.25 V +0.75 to +5.25 V
0..20 mA 0.00 to +20.90 mA +0.10 to +21.00 mA 0.00 to +21.00 mA
4..20 mA +3.00 to +20.90 mA +3.10 to +21.00 mA +3.00 to +21.00 mA
Table. User set values (PLC)
Range
Settable value by PLC
(Offset Binary
Signed Magnitude
2’s Complement)
Expected value
0..10 V 0 to 1050 0.00 to +10.50 V
0..5 V 0 to 525 0.00 to +5.25 V
1..5 V 75 to 525 +0.75 to +5.25 V
0..20 mA 0 to 2100 0.00 to +21.00 mA
4..20 mA 300 to 2100 +3.00 to +21.00 mA
: If the data format is scaled data format, set the data as follows, regardless of the range setting.
•PLC set value: 0 to 32767 → Converted value +0 to +32767
•PLC set value: 32768 to 65535 → Converted value -0 to -32767
