1 Name and Functions Parts

1 - 2

• IDFA3E

Membrane Grommet

Power cord outlet

Front

Electrical Terminal Cover

You can see the terminal block when

you remove this cover. Connect the

power cable through the membrane

grommet.

Customer Connection Side

Terminal Connecting Screw: M3

Applied Pressure Terminal: 1.25-3

(Width 6.5mm and below)

（）
