1-1 Parts Name and Functions
• IDFA3E
Front
Switch with Lamp
(ON/OFF Switch)
The lamp is continuously ON
during normal operation. Use it
for ON/OFF operations.
Evaporation thermometer
(EVAPORATING TEMP)
Indicates the temperature of
refrigerant of low-pressure
side.
During normal driving, it
indicates in the green zone.
Drain Tube
Discharges drain.
Auto Drain
It is covered with insulator, which
should not be removed.
No Front Panel
Top Ventilation Grille
(Outlet)
Hot air will be exhausted
from condenser by fan. No
obstacles shall be allowed
to place on top of it or even
close the grille.
Panel Lock
Another one is on the left side.
