9 Specification for Option K
9 - 2
9-2 Specifications
The auto drain has a maximum operating pressure of 1.6MPa and uses the metal case with a fluid
level indicator.
Model
Item
IDFA6E to 15E-23-K
Auto drain / Case Assembly
AD48-8-X2110
Part number : Note)
IDF-S0086
Max. operating pressure
1.6MPa
Auto drain type
Floating type
Auto drain valve type
N.O. (normally opened: Released without pressurization)
Working pressure
0.1 to 1.6MPa
Fluid
Compressed air
Note) The above part number does not include the auto drain strainer. If the strainer needs to be
replaced, order it.
(Part number for the auto drain strainer: IDF-S0002)
KQ2H10-02S
φ10
Fluid level indicator
Drain Port
Insulation
AD48-8-X2110
IDFA6E to 15E
