Chapter 3 Transporting and Installation
3.2 Installation
3-4
3.2.4 Installation of Brackets
z
If tie-down needed, please use the M6 screws which are located in the
side and bottom of this product. The screw must not enter by 30mm or
more in the product.
z
Refer to page7-1 “Outline Dimensions”.
Fig. 3-1 Screws for tie-down
Side
Bottom
