Figure 8 - Example (non-POE) ITV Data and Power Connections
12.1. SMC ITV POE Summary
The Power Over Ethernet (POE) feature is an optional way to power ITV units eliminating the need
to run a power cable to all ITVs. When POE is enabled, power is provided to the ITV by the “Bus In”
cable. The ITV factory default condition is POE disabled.
The POE on the ITV does not use the PoE 802.3 standard and therefore is not compatible
with these devices. The ITV Power Over Ethernet (POE) implementation is unique to the
SMC ITV. Do NOT operate other devices using the ITV POE. Do NOT use POE from other
devices to operate the ITV. By default, POE is DISABLED. Be sure that you FULLY
understand this section BEFORE enabling POE on your ITV network.
12.2. Configuring POE
POE is enabled or disabled using the “Enable POE” checkbox on the network tab. Login to the ITV
and press the “Network” menu item. The “Enable POE” check box is highlighted in the example
below.
Ethernet IP
Master Device
To Next Page
