SMC Networks ITV SEN DUX02357 Series

IN19856
- 53 - Rev 2
Press the “Local Area Connection” link (in Figure 34 - Windows Network and Sharing Center) and
the Local Area Connection Status window will appear. Then press the “Properties” button and
the Local Area Connection Properties window will appear:
Figure 35 - Windows Local Area Connection and Local Area Connection Properties
Next select Internet Protocol Version 4 (TCP/IPv4) and press the Properties button. The
Internet Protcol Version 4 (TCP/IPv4) Properties window will appear:
Figure 36 - Windows Internet Protocol - IPv4 – Properties
S
Change the PC subnet
value if needed to match
the ITV subnet
