A
PPLICATION
E
XAMPLES
2-3
Central Wiring Closet
With 24 parallel bridging ports (i.e., 24 distinct collision domains), this
switch can collapse a complex network down into a single efficient bridged
node, increasing overall bandwidth and throughput.
In the figure below, the 1000BASE-T RJ-45 ports on the switch are
providing 1 Gbps full-duplex connections for up to 24 local segments. In
addition, the switch is also connecting remote servers over fiber optic
cable at 1 Gbps.
Figure 2-2 Central Wiring Closet
10/100 Mbps Segments
...
...
10/100/1000 Switch
Server Farm
SMC8024L2
TigerSwitch 10/100/1000
12
78
12
3
4
5
6
9
10
11
13
14
15 16
17
18 19
20
21 22
23
24
Link/Act
Link/Act
Power
1000
1000
1234
13 14 15 16
5
67 8
17 18 19 20
9101112
21 22 23 24
21 22
23
24
