4-1
C HAPTER 4
M AKING N ETWORK
C ONNECTIONS
Connecting Network Devices
The TigerSwitch 10/100/1000 units are designed to interconnect multiple
segments (or collision domains). It can be connected to network cards in
PCs and servers, as well as to hubs, switches or routers. It may also be
connected to devices using optional SFP transceivers.
Twisted-Pair Devices
Each device requires an unshielded twisted-pair (UTP) cable with RJ-45
connectors at both ends. Use Category 5, 5e or 6 cable for 1000BASE-T
connections, Category 5 or better for 100BASE-TX connections, and
Category 3 or better for 10BASE-T connections.
Cabling Guidelines
The RJ-45 ports on the switch support automatic MDI/MDI-X pinout
configuration, so you can use standard straight-through twisted-pair cables
to connect to any other network device (PCs, servers, switches, routers, or
hubs).
See Appendix B “Cables” for further information on cabling.
Caution: Do not plug a phone jack connector into an RJ-45
port. This will damage the switch. Use only twisted-pair cables
with RJ-45 connectors that conform to FCC standards.

SMC Networks SMC8024L2 Specifications

General

Device Type	Switch
Switching Capacity	8.8 Gbps
MAC Address Table Size	8K entries
Features	Flow control, Quality of Service (QoS), port mirroring
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p
Jumbo Frame Support	Yes
Dimensions	440 x 200 x 44 mm
Power Supply	Internal
Ports	24 x 10/100 + 2 x SFP
