SMC Networks SMCWUSB-N4 User Manual

Using the SMC WLAN Configuration Tool (Windows)
34
SMCWUSB-N4 300 Mbps Wireless USB Adapter User Manual
To switch the Adapter from AP mode to Station mode, click Station mode at the top of the
main screen (see Figure 3-1).
Viewing Wireless Network Status
Mode: Station mode
Tab: Status
The Status tab shows the following information about the Adapter’s current wireless
connection.
Status = shows whether the Adapter is
connected or disconnected.
IP Address = IP address of the wireless
network to which the Adapter is connected.
SSID = name of the wireless network to
which the Adapter is connected.
Subnet Mask = subnet mask of the wireless
network to which the Adapter is connected.
Authentication Type = type of
authentication the adapter is using. To set
authentication, see pages 38 and 43.
Gateway = gateway to which the Adapter is
connected.
Encryption Type = type of encryption the
adapter is using. To set encryption, see
pages 38 and 43.
Speed = speed at which the Adapter is
currently working.
Network Type = type of network to which
the Adapter is connected (for example,
Infrastructure or Ad-Hoc).
Rx Throughput = download speed you are
currently experiencing.
Physical Address = MAC address of the
Adapter.
Tx Throughput = upload speed you are
currently experiencing.
