-43-
No. ZK2-OM01301
(9) DIN rail
AXT100-DR - 5
L = 12.5 x # + 10.5 (#: Length symbols 1 to 40)
(10) Connector housing assembly
ZK2-CH 2 04 -A
Length symbols
1
to
40
L Dimension
(When selecting the number, refer to “L6” in dimension table in the Best Pneumatics No.4 catalog.)
No.
1
2
3
4
5
6
7
8
9
10
L Dimension
23
35.5
48
60.5
73
85.5
98
110.5
123
135.5
No.
11
12
13
14
15
16
17
18
19
20
L Dimension
148
160.5
173
185.5
198
210.5
223
235.5
248
260.5
No.
21
22
23
24
25
26
27
28
29
30
L Dimension
273
285.5
298
310.5
323
335.5
348
360.5
373
385.5
No.
31
32
33
34
35
36
37
38
39
40
L Dimension
398
410.5
423
435.5
448
460.5
473
485.5
498
510.5
Connector type
1
D-sub connector (25 pins)
2
Flat ribbon cable connector (26 pins)
Applicable stations
02
For 2 stations manifold
04
For 4 stations manifold
06
For 6 stations manifold
08
For 8 stations manifold
10
For 10 stations manifold
