SMC Networks ZSE30 Series User Manual

+
–
Brown DC (+)
Black OUT
Blue DC (–)
FUNC
Load
+
–
Load
Brown DC (+)
Black OUT
Blue DC (–)
FUNC
12 to
24 VDC
Brown DC (+)
Black OUT1
White OUT2
FUNC
Blue DC (–)
Load
Load
+
–
12 to
24 VDC
Brown DC (+)
Black OUT1
White OUT2
FUNC
Blue DC (–)
Load
Load
+
–
12 to
24 VDC
12 to
24 VDC
Main circuit
Main circuit Main circuit
Main circuit
Internal Circuits and Wiring Examples
Max. 80 mA
Residual voltage 1 V or less
Max. 28 V, 80 mA
Residual voltage 1 V or less
Max. 80 mA
Residual voltage 1 V or less
Max. 28 V, 80 mA
Residual voltage 1 V or less
Z/ISE30A
(
F
)
Output
NPN (1 output)
N
NPN (2 outputs)
A
PNP (2 outputs)
B
PNP (1 output)
P
∗ The FUNC terminal is connected using a dedicated lead wire (ZS-38-5L or ZS-38-U) when the copy function is used. (Refer to “Copy function” on page 10.)
4
Series ZSE30A
(
F
)
/ISE30A
